Advantages:

1. Supplies chilled water for food product cooling processes. Also provides chilled water for the second stage of plate heat exchangers.

2. State-of-the-art equipment designed for the lowest energy consumption on the market.

3. High refrigerant fluid efficiency, using only 50 or 100 liters of eutectic solution (water + alcohol), compared to conventional units with tanks exceeding 200 liters. This reduced volume ensures fast start-up and energy savings.

4. Integrated filtration system for the eutectic solution.

5. Compact design, allowing installation in limited spaces.

6. Protection against short circuits, overloads, and chilled water circulation failures.

7. Hermetic SCROLL compressor (approximately 10% lower energy consumption compared to semi-hermetic compressors).

8. Vacuum-brazed plate evaporator, manufactured entirely in copper.

9. Brazing material composed of 99.9% copper.

10. Stainless steel connections.

11. Tube-in-Tube condenser (all water-contact components made of copper).

12. Thermostat for precise temperature control.

13. High-pressure condensation pressure switch.

Notes:

* Technical specifications are subject to change without prior notice.

** Declared production capacity may vary according to local climate conditions and installation setup.

Technical Specifications

Wattage: 6,5 – 7,5 kW

Crate Dimensions: ---

Equipment Dimensions: 900 x 700 x 1000 mm

Gross Weight, With Crate: ---

Liquid weight: 120 kg

Production Capacity: 300 a 600 litros / hora
